WordPress Varnish Setup

75

wordpress-varnish

1. Windows DNS Tweaks

  • Chrome DNS cleanup
  • Windows Pointing

    Windows Overriding to point to Different name-server/VPS to test
    C:\WindowsSystem32driversetchost

  • Clear Windows DNS Cache
    • ipconfig /flushdns

2. WordPress Varnish HTTPS Setup

Using Nginx as a proxy is the easiest and powerful method to use SSL on a Varnish scenario, all incoming SSL traffic on 443 port will be redirected by nginx to varnish on port 80. Workflow:

Nginx(SSL) -> Varnish(caching) -> Apache(back-end) -> WordPress(app)

Setup Configuration

HTTPS Request => NginX (443) => Varnish Server(80) => Apache Server(8080)
HTTP Request => Varnish Server(80) => Apache Server(8080)
Proxy Server)=> (Cache Server) => Backend WordPress CMS

Commands

Nginx
sudo systemctl stop nginx
sudo systemctl restart nginx
netstat -ntlp | grep ng

Varnish
sudo systemctl restart varnish
sudo systemctl stop varnish
netstat -ntlp | grep varn

Apache
sudo systemctl restart httpd.service
sudo systemctl stop httpd.service
netstat -ntlp | grep httpd

Configurations

  1. Ngnix
    vi /etc/nginx/availablesites/wordzz.com.conf
    server {
            listen 443 ssl;

            server_name wordzz.com;
            ssl on;
            ssl_certificate /etc/letsencrypt/live/wordzz.com/fullchain.pem;
            ssl_certificate_key /etc/letsencrypt/live/wordzz.com/privkey.pem;


            location / {
                proxy_pass http://127.0.0.1:80;
                proxy_set_header X-Real-IP  $remote_addr;
                proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
                proxy_set_header X-Forwarded-Proto https;
                proxy_set_header X-Forwarded-Port 443;
                proxy_set_header Host $host;
            }
    }

2. Varnish

Varnish change 127.0.0.1 and 8080 (new listening port)
Earlier 80 to Listen 8080

vi /etc/varnish/default.vcl
(Also Replace Varnish Config with below for optimization)

Varnish Commands

varnishtop -i BereqURL
varnishstat
varnishhist

3. Apache

Step 1: Running Backend Server on 8080 port
vi /etc/sentora/configs/apache/port/port.conf
Listen 80 ->8080

Step 2: Change HTTP Domain port as-well to 8080
vi /etc/sentora/configs/apache/domains/wordzz.com.conf
# DOMAIN: wordzz.com

Step 3: Change HTTPS to different port(it doesn’t matter)
vi /etc/httpd/conf.d/ssl.conf
Listen 9443
&&
ServerAlias www.wordzz.com

Step 4: Reference Main Config File
vi /etc/httpd/conf/httpd.conf

Finally:
it should be working
curl -ik http://127.0.0.1:8080

Avoid HTTPS redirection

1. WP-Config
wp-config.php must have this line at the very top:

if ($_SERVER[‘HTTP_X_FORWARDED_PROTO’] === ‘https’){ $_SERVER[‘HTTPS’]=’on’; }

define(‘FORCE_SSL_ADMIN’, true);
//define(‘WP_HOME’,’https://www.wordzz.com’);
//define(‘WP_SITEURL’,’https://www.wordzz.com’);

2 .htacess changes

<IfModule mod_rewrite.c>
RewriteEngine On
RewriteCond %{HTTPS} !=on
RewriteCond %{HTTP:X-Forwarded-Proto} !https
RewriteRule ^ https://%{HTTP_HOST}%{REQUEST_URI} [L,R=301]
</IfModule>

Reference: Varnish Config Dump

    #
    # This is an example VCL file for Varnish.
    #
    # It does not do anything by default, delegating control to the
    # builtin VCL. The builtin VCL is called when there is no explicit
    # return statement.
    #
    # See the VCL chapters in the Users Guide at https://www.varnish-cache.org/docs/
    # and https://www.varnish-cache.org/trac/wiki/VCLExamples for more examples.

    # Marker to tell the VCL compiler that this VCL has been adapted to the
    # new 4.0 format.
    vcl 4.0;

    # Default backend definition. Set this to point to your content server.
    backend default {
        .host = "10.0.0.10";
        .port = "80";
        .connect_timeout = 600s;
        .first_byte_timeout = 600s;
        .between_bytes_timeout = 600s;
        .max_connections = 800;
    }

    # Only allow purging from specific IPs
    acl purge {
        "localhost";
        "127.0.0.1";
        "10.0.0.10";
    }

    # This function is used when a request is send by a HTTP client (Browser)
    sub vcl_recv {
            # Normalize the header, remove the port (in case you're testing this on various TCP ports)
            set req.http.Host = regsub(req.http.Host, ":[0-9]+", "");

            # Allow purging from ACL
            if (req.method == "PURGE") {
                    # If not allowed then a error 405 is returned
                    if (!client.ip ~ purge) {
                            return(synth(405, "This IP is not allowed to send PURGE requests."));
                    }
                    # If allowed, do a cache_lookup -> vlc_hit() or vlc_miss()
                    return (purge);
            }

            # Post requests will not be cached
            if (req.http.Authorization || req.method == "POST") {
                    return (pass);
            }

            # --- WordPress specific configuration

            # Did not cache the RSS feed
            if (req.url ~ "/feed") {
                    return (pass);
            }

            # Blitz hack
            if (req.url ~ "/mu-.*") {
                    return (pass);
            }


            # Did not cache the admin and login pages
            if (req.url ~ "/wp-(login|admin)") {
                    return (pass);
            }


            # Remove the "has_js" cookie
            set req.http.Cookie = regsuball(req.http.Cookie, "has_js=[^;]+(; )?", "");

            # Remove any Google Analytics based cookies
            set req.http.Cookie = regsuball(req.http.Cookie, "__utm.=[^;]+(; )?", "");

            # Remove the Quant Capital cookies (added by some plugin, all __qca)
            set req.http.Cookie = regsuball(req.http.Cookie, "__qc.=[^;]+(; )?", "");

            # Remove the wp-settings-1 cookie
            set req.http.Cookie = regsuball(req.http.Cookie, "wp-settings-1=[^;]+(; )?", "");

            # Remove the wp-settings-time-1 cookie
            set req.http.Cookie = regsuball(req.http.Cookie, "wp-settings-time-1=[^;]+(; )?", "");

            # Remove the wp test cookie
            set req.http.Cookie = regsuball(req.http.Cookie, "wordpress_test_cookie=[^;]+(; )?", "");

            # Are there cookies left with only spaces or that are empty?
            if (req.http.cookie ~ "^ *$") {
                        unset req.http.cookie;
            }

            # Cache the following files extensions
            if (req.url ~ ".(css|js|png|gif|jp(e)?g|swf|ico)") {
                    unset req.http.cookie;
            }

            # Normalize Accept-Encoding header and compression
            # https://www.varnish-cache.org/docs/3.0/tutorial/vary.html
            if (req.http.Accept-Encoding) {
                    # Do no compress compressed files...
                    if (req.url ~ ".(jpg|png|gif|gz|tgz|bz2|tbz|mp3|ogg)$") {
                                    unset req.http.Accept-Encoding;
                    } elsif (req.http.Accept-Encoding ~ "gzip") {
                            set req.http.Accept-Encoding = "gzip";
                    } elsif (req.http.Accept-Encoding ~ "deflate") {
                            set req.http.Accept-Encoding = "deflate";
                    } else {
                            unset req.http.Accept-Encoding;
                    }
            }

            # Check the cookies for wordpress-specific items
            if (req.http.Cookie ~ "wordpress_" || req.http.Cookie ~ "comment_") {
                    return (pass);
            }
            if (!req.http.cookie) {
                    unset req.http.cookie;
            }

            # --- End of WordPress specific configuration

            # Do not cache HTTP authentication and HTTP Cookie
            if (req.http.Authorization || req.http.Cookie) {
                    # Not cacheable by default
                    return (pass);
            }

            # Cache all others requests
            return (hash);
    }

    sub vcl_pipe {
            return (pipe);
    }

    sub vcl_pass {
            return (fetch);
    }

    # The data on which the hashing will take place
    sub vcl_hash {
            hash_data(req.url);
            if (req.http.host) {
                 hash_data(req.http.host);
            } else {
                 hash_data(server.ip);
            }

            # If the client supports compression, keep that in a different cache
            if (req.http.Accept-Encoding) {
                 hash_data(req.http.Accept-Encoding);
            }

            return (lookup);
    }


    # This function is used when a request is sent by our backend (Nginx server)
    sub vcl_backend_response {
            # Remove some headers we never want to see
            unset beresp.http.Server;
            unset beresp.http.X-Powered-By;

            # For static content strip all backend cookies
            if (bereq.url ~ ".(css|js|png|gif|jp(e?)g)|swf|ico") {
                    unset beresp.http.cookie;
            }

            # Only allow cookies to be set if we're in admin area
            if (beresp.http.Set-Cookie && bereq.url !~ "^/wp-(login|admin)") {
                    unset beresp.http.Set-Cookie;
            }

            # don't cache response to posted requests or those with basic auth
            if ( bereq.method == "POST" || bereq.http.Authorization ) {
                    set beresp.uncacheable = true;
                    set beresp.ttl = 120s;
                    return (deliver);
            }

            # don't cache search results
            if ( bereq.url ~ "?s=" ){
                    set beresp.uncacheable = true;
                    set beresp.ttl = 120s;
                    return (deliver);
            }

            # only cache status ok
            if ( beresp.status != 200 ) {
                    set beresp.uncacheable = true;
                    set beresp.ttl = 120s;
                    return (deliver);
            }

            # A TTL of 24h
            set beresp.ttl = 24h;
            # Define the default grace period to serve cached content
            set beresp.grace = 30s;

            return (deliver);
    }

    # The routine when we deliver the HTTP request to the user
    # Last chance to modify headers that are sent to the client
    sub vcl_deliver {
            if (obj.hits > 0) {
                    set resp.http.X-Cache = "cached";
            } else {
                    set resp.http.x-Cache = "uncached";
            }

            # Remove some headers: PHP version
            unset resp.http.X-Powered-By;

            # Remove some headers: Apache version & OS
            unset resp.http.Server;

            # Remove some heanders: Varnish
            unset resp.http.Via;
            unset resp.http.X-Varnish;

            return (deliver);
    }

    sub vcl_init {
            return (ok);
    }

    sub vcl_fini {
            return (ok);
    }
